Features
|
 |
Easy to use |
|
Fast, Accurate amp; Portable |
|
Large LCD |
|
Accessible Line Fuse |
|
Selectable Test Loads |
|
Calibrated Test Points |
|
15 and 20 Amp capability |
|
Complies with AAMI or IEC 610-1 Test Load Loads | |
Specifications
Display
3 1/2 Digit LCD Display
Leakage Current
0-1999 micro amps. All Current measurements are made through the AAMI/ANSI ESI - 1985 or IEC 601 - 1 test loads.
The meter readings correspond to the true RMS value of the current
Accuracy:
DC to 1 kHz: +/- 1% of reading, +/- 1 LSD
1 kHz to 100 kHz: +/- 2.5% of reading +/- 1 LSD
100 kHz to 1 mHz: +/- 5% of reading +/- LSD
Resistance:
0 to 1999 milliohms.
Accuracy is +/- 1% of reading +/- 1 LSD
Device Current :
0 to 19.99 amps. Accuracy is +/- 2% of FS +/- 1LSD
Measures Ground Resistance, Internal and External Leakage Current, and Instrument Current.
Test Receptacle
Hospital Grade 110V AC - 15 amp or 220V AC 10 amp.
The rocker polarity switch selects NORMAL, OFF and REVERSE Polarity to the test receptacle, and a momentary Neutral switch will open the neutral line to the test receptacle
Power Requirements
110V AC 50 - 60 Hz, 15 amps or 220V AC, 10 amps maximum rated for the test outlet and 0.1 amp rated for the unit.
Ambient Temperature
Operating Range: 59 to 95 degrees F (15 to 40 degrees C)
Storage Temperature: 0 to 122 degree F (-20 to 60 degree C)
Relative Humidity: 90% (max) at temperatures
Physical Dimensions
Size: 5.5 x 3.25 x 2.5inches (13.75 x 8.13 x 6.25 cms)
Weight: 1 lbs (0.45 kg)
