Features
|
 |
Large LCD Display |
|
Clean Microvolt Signals |
|
Selectable Amplitudes |
|
Selectable Frequencies |
|
Compact, Rugged Case | |
Specifications
EEG Output Connections
Five separate floating outputs are provided through patented EEG spring loaded connections marked
E1+, E2+, E3+, E4+, E5+
and
E1-, E2-, E3-, E4-, and E5-.
The two reference outputs are marked Ref.
Waveforms:
ABR Waveform:
Frequency: 1 kHz
Amplitute: 0.64 microVolt
Sine, Square, and Triangle:
Frequencies: 0.1, 0.5, 2, 50, and 60 Hz.
Amplitude: 10, 30, 50, 100, 500 microVolt, 1, 2, and 2.5 milliVolt
Key Pad
8 tactile membrane Keypad
Display
2 line 16 character LCD Display
Case
High Impact Plastic
Power Requirements:
9V Alkaline Battery.
Optional AC Adapter
Environmental:
Operating Range:
59 to 95 Degrees F (15 to 35 Degrees C)
Storage Range:
32 Degrees to 122 Degrees F (0 to 55 Degrees C)
Physical Dimensions:
Size:
5.5 x 3.5 x 1.5 inches
(13.75 x 8.75 x 3.75)
Weight:
10oz (0.28 kg)
