- Automatic heating,infusion at constant temperature
- Large size multi color LCD screen
- All data synchronized display, easy to operate
- Door-free structure
- Alarm functions
- Compatible with IV sets of any Brand with high accuracy
Performance Parameter
- Standard mode infusion rate: 1mL/h~1300mL/h
- Max. volume limit : 9999mL (minimum increment 1mL)
- Max. volume accumulated: 9999mL (minimum increment 0.01mL)
- BOLUS and PRIME rate : 600mL/h, 700mL/h, 800mL/h, 900mL/h, 1000mL/h
- KVO rate: OFF or 1.0mL/h~5.0mL/h (auto mode)
- Accuracy: ��5%
- Occlusion alarm threshold: 300mmHg, 500mmHg, 700mmHg, 900mmHg, 1100mmHg
- Air Bubble Detect: not less than 30��10-3mL
- Pump Working Noise: Without Alarms, IP300��s working noise should be under 45dB (A).
- Alarm Volume: Alarm volume should be over 65dB (A) during alarms.
- Battery Capability: Infusion Pump can work under intermittent rate (25ml/h) longer than 4 hours (at 20��C)
Alarm
Failure, Low battery, AC failure, Door open, Occlusion, Air in line, Infusion finished (Auto switch to KVO)
Power supply
- AC power: AC100 to 240V, 50Hz/60Hz
- Battery: NiMH 9.6V
- Power consumption: ��30 VA
Physical specification
- Dimensions: 240mm(H)��110mm(W)��230mm(D)
- Weight: ��3.5 kg (packaging-free)
- Screen: Large multi color LCD
Environment requirements
- Temperature Operation: +5��C~+40��C (special), +15��C ~+40��C (standard)
- Storage: -20��C ~+55��C
- Relative humidity Operation: 20%~90%
- Storage: ��93%
- Atmospheric Pressure Operation: 70~106kPa
- Storage: 50~106kPa
- Altitude Operation: 500~800mmHg (3565 ~ -440m)
- Storage: 375~800mmHg (5860 ~ -440m)
