Specification
Input Circuit : Floating; Protection against Defibrillator effect
Lead: Standard 12 leads ,Lead change automatically
Patient Current Leakage:<10 µ A
Input Impedance:=50 ?O
Calibrating Voltage: 1mV ±3%
A/D Conversion:12 bit
Display:320×240LCD
Frequency Response:0.05Hz-150Hz
Time Constant:>3.2seconds
CMRR:>80d>100dB(with filter)
Paper Speed:25,50mm/s±3%
Recording Paper: 210mm×30m, A4 size
Input Circuit Current: =50nA
Safety Standard: IEC class I, type CF
Sensitivity: 1/2,1,2(cm/mV)
Skin Voltage Tolerance: ±300mV
Noise Level:<15 µVp-p
Weight: 5.1kg
Specification:
Simultaneous 12 leads acquisition and printing
Automatic measurement and interpretation;R-R analysis
12 leads simultaneous display on large backlight LCD 320×240
Digital design and filter;Thermal array printer
Recording on A4 size paper
Baseline auto-adjustable;Rhythm lead selectable
DC/AC autoexchange,built-in rechargeable battery.Power supports continuously working for more than 50 patients
16 pieces of unzipped ECG date and waveforms are stored for copy and re-call
Inner handhold designed for portability
