Specification
Input Circuit : Floating; Protection against Defibrillator effect

Lead: Standard 12 leads ,Lead change automatically

Patient Current Leakage:<10 µ A

Input Impedance:=50 ?O

Calibrating Voltage: 1mV ±3%

A/D Conversion:12 bit

Display:320×240LCD

Frequency Response:0.05Hz-150Hz

Time Constant:>3.2seconds

CMRR:>80d>100dB(with filter)

Paper Speed:25,50mm/s±3%

Recording Paper: 210mm×30m, Roll paper

Input Circuit Current: =50nA

Safety Standard: IEC class I, type CF

Sensitivity: 1/2,1,2(cm/mV)

Skin Voltage Tolerance: ±300mV

Noise Level:<15 µVp-p

Weight: 5.1kg
Features:
Simultaneous 12 leads acquisition and printing
Automatic measurement and interpretation;R-R analysis
12 leads simultaneous display on large backlight LCD 320×240
Digital design and filter ;Thermal array printer
Baseline auto-adjustable;Rhythm lead selectable
DC/AC autoexchange,built-in rechargeable battery.Power supports continuously working
for more than 50 patients
