14 languages: English, Spanish, Portuguese, Czech, Denish, Finland, Italian, Polish, Turkish, Chinese, French, Russian, German, Dutch Pitch tone
Big font display interface
Trend graph display interface
OxyCRG display interface
ECG, NIBP, SPO2, TEMP interface
Standard display interface
Battery, Record
ECG full lead display interface
Display with 9 waveform
720 hours trend data
1000 NIBP data storage
200 alarm event data storage
Sound, light, human voice alarm
12 hours waveform review
Wire and wireless network
Support software upgrade online
Arrhythmia analysis, ST segment analysis
Support touch screen
Standard: ECG, RESP, NIBP, SPO2, TEMP
Optional: Recorder, IBP, EtCO2, touch screen
Specifications
Size and Weight
size 273×203×91mm
Weight 1.5 kg
a.c. 100V~240 V, 50Hz/60 Hz, Pmax=90VA, Fuse T1.5AL 250V
2.3 Ah 12V rechargeable battery
Operating time after full charge is more than 1 hours
Operating time after the first alarm of low battery will be about 5 minutes
Maximum charging time is less than 6 hours.
Network interface standard RJ45 Socket
Trend 720 hours
NIBP review 1000 NIBP events
Wave review 2 hours
Alarm review 200 alarm events
All storage data are non volatile.
Temperature
Working 0 ~ 40 °C
Storage -20 ~ 50°C
Humidity
Working 15% - 90 %
Storage 15% - 90 % (no coagulation)
Atmospheric pressure
Working 86.0 kPa ~ 106.0kPa;
Storage 86.0 kPa ~ 106.0kPa
