HANDHELD TELE ECG

Handheld Tele ECG



Tele ECG electronic device using mobile cellular network operated with the help of a mobile phone via bluetooth.  It records ECG of the  subject and display  the  same on mobile. After complete recording the ECG can be sent to the experts mobile through  multimedia service  (MMS)  for his opinion.

Tele ECG can also be operated through laptop or desktop in lieu of a mobile phone in

hospitals having local area network.





Features

• Low cost, portable and compact

• Mobile as well as LAN connectivity

• Acquisition, processing, storing and visualization of ECG in real time

• Using a secure GPRS connection for transfer of  ECG  data



Specification

• Principle : Bio-potential sensing by surface electrodes

• Configuration : Einthoven 12 Leads, one at a time.

• Input Impedance : > 10 M

• Gain : 1000/500 (User Selectable)

• CMRR : 90 dB

• Connectivity : Mobile - Mobile*via GPRS

  Mobile - PC via internet

  Unit - Mobile/PC via Bluetooth

• Mobile having Bluetooth and J2ME support



Applications

• The ECG  system  is of considerable  importance  for  developing  countries,

  where more than 70% of the population inhabits rural areas and has meager

  access to medical facilities. This large section can now be provided state-of-

  the art medical care  with such Tele-systems.

• This  unit  can  also  be  used  for  personal  monitoring  in  the  urban

  population with established coronary artery disease patients  for regular  follow

  up.

• The  unit  has  been  upgraded  for  hospital  use  having  Locan  Area

  regular follow up.

 • The  unit  has  been  upgraded  for  hospital  use  having  Local  Area

   Network.
