l 10.4�� TFT color screen
l Easy setting by navigator wheel knob and touch key
l Flow and pressure trigger
l Compliance and Resistance monitor
l Three-level light and sound alarm, with concise words describing problems
l Advanced built-in electronic Air-oxygen mixing device
l Durable and accurate built-in flow sensor
l Integrated expiration valve, easy to be sterilized
l Backup apnea ventilation
Technical Data
ž Ventilation mode: VCV, PCV, SIMV-V, SIMV-P, PSV, SPONT, CPAP, APRV(optional), BIPAP(optional)
ž Tidal volume��50��1500mL
ž Breath rate: 1~100bpm
ž SIMV breath rate: 1~40bpm
ž Inspiratory time: 0.1~12s
ž Pause time: 0~4.8s
ž Pressure trigger sensitivity: (PEEP-20cmH2O)��PEEP cmH2O
ž Flow trigger sensitivity: 1~20LPM
ž PSV: 0~70cmH2O
ž PCV: 5~70cmH2O
ž Low pressure: 0~79cmH2O
ž Waveforms displayed: P-T, F-T,V-T, P-V loop, V-F loop
ž PEEP/CPAP: 0~50cmH2O
ž FiO2: 21%~100%
ž Alarm silence: ��120s
ž Parameters monitored: Vti, Vte, MV, FiO2, Ppeak, Pplat, Pmean, PEEP, Fspont, MV spont, Compliance, Resistance
ž Interface: RS232,VGA
ž Insp Hold; Exp Hold; Manual Insp; O2 Suction; FREEZE
ž Pressure safety valve: ��10kPa
Operation Environment
ž Power: AC110~240V: 50~60Hz
ž Power Consumption: 65VA
ž SIZE (Width��Height��Depth) : 400��350��300mm
ž Weight: 15Kg (Main Unit)
ž Drive mode: pneumatically driven, electronically controlled
ž Setting: Knob
ž Gas supply: Air & Oxygen, Pressure0.28~0.6Mpa, >50L/min
